Distro Type 3614

/ Equipment / Power & Distro / Three Phase HP

Distro Type 3614

Input : 1 x 63A 3PH (100A C-Type MCB)



Output : 6 x 16A 1PH (16A C-Type RCBO x6)

Output : 6 x 16A 1PH (16A B-Type RCBO x6)

Output : 6 x 32A 1PH (32A C-Type RCBO x6)

Output : 2 x 32A 3PH (32A C-Type MCB & Variable / Switchable RCD x2)



Through : 1 x 63A 3PH



This Unit also has an external Earthing point



Weight : 17.50kg

Specifications
  • Category:
  • Input: 63A, Three Phase
  • Output: 16A, Single Phase, 32A, Three Phase, 32A, Single Phase, 63A, Three Phase
  • Housing Type: Rubber Box
Downloads:
Distro Guide
