Ayrton Rivale Profile
/ Equipment / Moving Intelligent Fixtures / Moving Profiles
Ayrton Rivale Profile
- IP65 rated
- 30,000lm total output
- 4° to 52° beam aperture
- 13-element 13:1 zoom high-resolution optic system and fast motorised linear zoom
- Tempered anti-reflective coated lenses and 160mm frontal lens
- 6,500K colour temperature
- Flicker-free source management
- Native CRI greater than 70
- Pan and tilt automatic repositioning and infinite rotation
- CMY colour mixing with variable CTO colour temperature correction and fixed colour wheel
- Indexable, adjustable-speed and bi-directional rotating gobo wheel with seven glass gobos and open position
- Fixed gobo wheel with nine glass gobos and open position
- Four individually positionable shutter blades with module rotation of +/- 90°
- Fast iris diaphragm with adjustable dynamic effects (15% to 100% open)
- Two frost filters (light and heavy)
- Focusable graphic animation effect-wheel with continuous bi-directional rotation
- 2 combinable rotating and indexable prisms (one 5-facet circular and one 4-facet linear)
The Rivale Profile is perfectly homothetic and shares common features with other fixtures in Ayrton's Ultimate series to produce incredible weight to output ratios. Developed for use in all conditions, this fixture has continuous rotation on pan and tilt movement. The high-efficiency 430W sealed mono-block LED module calibrated at 6500K offers a luminous flux of 30,000 lumens with optimal positioning on a black body to obtain perfect light neutrality. Equipped with a 160mm frontal lens and a proprietary optical system has 13 lenses, delivering a 13-to-1 zoom ratio and zoom range of 4° to 52°
New high-definition progressive CMY colour mixing system to deliver perfect colour reproduction when filter is inserted, regardless of the colour combination selected. An extended progressive CTO enables fine tuning of the colour temperature from 2700K to 6500K, and a seven-position colour wheel completes the palette of tools dedicated to creating colour. For greater flexibility of use, Rivale Profile allows subtle adjustment of the colour rendering index from 70 to 86. The framing section permits accurate positioning of each shutter blade on a 100% surface area with a rotation of plus-or-minus 90°. A fast 15-blade iris diaphragm enables beam optimisation in Beam mode. The image section of Rivale Profile includes 15 high-definition glass gobos on two wheels: one rotating wheel with seven positions and one fixed wheel with eight positions. The effect section is fitted with a monochromatic animation wheel, two combinable rotating prisms and two frost filters. Rivale Profile, a unique projector that boasts performance, creativity, subtlety and power. Specifications
- Category: Moving Outdoor, Moving Profiles, Outdoor Lighting
- Manufacturer: Aytron
- Light Source: LED
- LED Engine: White
- Colour Mixing: CMY +CTO
- Shutters: Yes
- IP Rating: IP65
- Power Consumption (Watts): 700
- Housing Colour: Black
- pa_weight: 631
